Camera
Image Sensor	1/3” sensor
Min. Illumination	0.028 lux@F2.0, AGC ON 0 lux with IR
Shutter Speed	1/25s ~ 1/100,000s
Lens	4mm@F2.0 1280 × 960: angle of view: 73.1°
Lens Mount	M12
Angle adjustment	Pan: 0° ~ 355°, tilt: 0° ~ 65°
Day & Night	ICR
Digital Noise Reduction	3D DNR
Wide Dynamic Range	Digital WDR
Compression Standard
Video Compression	H.264 / MJPEG
H.264 codec profile	Main profile
Bit Rate	32 Kbps ~ 16 Mbps
Dual stream	Yes
Max. Resolution	1280 × 960
Frame Rate	60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720) 50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720)
Image Settings	Saturation, brightness, contrast adjustable through client software or web browser
BLC	Yes,zone configurable
Network
Network Storage	NAS ( iSCSI optional)
Alarm Trigger	Motion detection,tampering alarm,network disconnect,IP address conflict,storage exception
Protocols	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional)
System Compatibility	ONVIF, PSIA, CGI
General functionalities	Flickerless, heartbeat, mirror, user authentication, video mask, watermark
Interface
Communication Interface	1 RJ45 10M / 100M ethernet port
General
Working Temperature /Humidity	-13°F ~ 140°F(-25°C ~ 60°C) humidity 95% or less (non-condensing)
Power Supply	DC12V ± 10%, PoE (802.3af)
Power Consumption	Max. 5.5W
Impact protection	IEC60068-275Eh, 50J; EN50102, up to IK10
Ingress protection level	IP66
IR Range	Approx 65 to 100 ft(About 20 to 30m)
Dimension	Φ4.4”x3.2”(Φ111.0 × 82.4 mm )
Weight	1.1lb(500g)
